CX-T 20
Change unit:
/
|
Truck axle configurations |
6 x 4 - 6 x 6 - 8 x 4 (3 / 4) | 6 x 4 - 6 x 6 - 8 x 4 (3 / 4) |
|
Engine Power |
205 - 727 kW | 274 - 974 HP |
|
Emission Level |
Stage 3A/Tier 3 Stage 5/Tier 4f |
Stage 3A/Tier 3 Stage 5/Tier 4f |
|
Retract force |
20.000 daN | 44,962 lbs |
|
Feed force |
12.000 daN | 26,977 lbs |
|
Feed stroke |
7.000 mm | 22' 11" |
|
Rotary max torque |
37.500 Nm | 27,659 lb*ft |
|
Rotary max speed |
150 rpm | 150 rpm |
|
Clamping range |
45 - 365 mm | 1" 3/4 - 1' 2" |
|
Compressor flow |
33.000 Lt/min | 1,165 cfm |
|
Compressor pressure |
35 bar | 508 psi |
|
Weight range |
20 - 26 t | 44,092 - 57,320 lbs |
| Safety systems | ||
|---|---|---|
| Safety Protection Cage | ||
| Dust Diverter & Suppression Hood | ||
| Rod handling systems | ||
|---|---|---|
| Pipe Loader Arm | ||
| Compressor | ||
|---|---|---|
| On Board Compressor | ||
