CX-T 20
Change unit:
/
|
Truck axle configurations |
6 x 6 - 8 x 4 - 8 x 6 (3 / 4) | 6 x 6 - 8 x 4 - 8 x 6 (3 / 4) |
|
Engine Power |
205 - 225 kW | 274 - 301 HP |
|
Emission Level |
Stage 3A/Tier 3 Stage 5/Tier 4f |
Stage 3A/Tier 3 Stage 5/Tier 4f |
|
Retract force |
20.000 daN | 44,962 lbs |
|
Feed force |
12.000 daN | 26,977 lbs |
|
Feed stroke |
4.500 mm | 14' 9" |
|
Rotary max torque |
15.200 Nm | 11,211 lb*ft |
|
Rotary max speed |
1.250 rpm | 1,250 rpm |
|
Chuck Passage |
124 mm | 4" 7/8 |
|
Fluid Circulation Pump |
142 Lt/min - 70 bar | 37.5 gpm - 1,015 psi |
|
Wire-line winch |
2.200 m | 7,217' 10" |
|
Max pull up force |
13 kN | 2,866 lbs |
|
Weight range |
18 - 20 t | 39,683 - 44,092 lbs |
| Safety systems | ||
|---|---|---|
| Safety Protection Cage | ||
| Rod handling systems | ||
|---|---|---|
| Pipe Loader Arm | ||
