CX-T 15

Change unit: /

Truck axle configurations	4 x 4 - 6 x 4 - 6 x 6 (2 / 3)	4 x 4 - 6 x 4 - 6 x 6 (2 / 3)
Engine Power	168 - 690 kW	225 - 925 HP
Emission Level	Stage 3A/Tier 3 Stage 5/Tier 4f	Stage 3A/Tier 3 Stage 5/Tier 4f
Retract force	15.000 daN	33,721 lbs
Feed force	7.000 daN	15,737 lbs
Feed stroke	7.000 mm	22' 11"
Rotary max torque	20.000 Nm	14,751 lb*ft
Rotary max speed	210 rpm	210 rpm
Clamping range	45 - 365 mm	1" 3/4 - 1' 2"
Compressor flow	33.000 Lt/min	1,165 cfm
Compressor pressure	35 bar	508 psi
Weight range	14 - 25 t	30,865 - 55,116 lbs

Safety systems
Safety Protection Cage
Dust Diverter & Suppression Hood

Rod handling systems
Pipe Loader Arm

Compressor
On Board Compressor

Download the technical data sheet

CX-T 15 render

Discover our RC rigs

CX-T 10

CX-T 20

CX-T 30
