CX-T 15

Change unit: /

Truck axle configurations	4 x 4 - 6 x 4 - 6 x 6 (2 / 3)	4 x 4 - 6 x 4 - 6 x 6 (2 / 3)
Engine Power	168 - 205 kW	225 - 274 HP
Emission Level	Stage 3A/Tier 3 Stage 5/Tier 4f	Stage 3A/Tier 3 Stage 5/Tier 4f
Retract force	15.000 daN	33,721 lbs
Feed force	7.000 daN	15,737 lbs
Feed stroke	4.000 - 5.000 mm	13' 1" - 16' 4"
Rotary max torque	15.200 Nm	11,211 lb*ft
Rotary max speed	1.250 rpm	1,250 rpm
Chuck Passage	124 mm	4" 7/8
Fluid Circulation Pump	142 Lt/min - 70 bar	37.5 gpm - 1,015 psi
Wire-line winch	2.200 m	7,217' 10"
Max pull up force	13 kN	2,866 lbs
Weight range	14 - 16 t	30,865 - 35,274 lbs

Safety systems
Safety Protection Cage

Rod handling systems
Pipe Loader Arm
