CX-T 10

Change unit: /

Truck axle configurations	4 x 4 (2)	4 x 4 (2)
Engine Power	119 - 140 kW	160 - 188 HP
Emission Level	Stage 3A/Tier 3 Stage 5/Tier 4f	Stage 3A/Tier 3 Stage 5/Tier 4f
Retract force	9.000 daN	20,233 lbs
Feed force	6.500 daN	14,613 lbs
Feed stroke	4.000 mm	13' 1"
Rotary max torque	8350 Nm	6,159 lb*ft
Rotary max speed	1.500 rpm	1,500 rpm
Chuck passage	124 mm	4" 7/8
Fluid Circulation Pump	142 Lt/min - 70 bar	37.5 gpm - 1,015 psi
Wire-line winch	1.200 m	3,937'
Max pull up force	10 kN	2,205 lbs
Weight range	10 - 12 t	22,046 - 26,455 lbs

Safety systems
Safety Protection Cage

Rod handling systems
Pipe Loader Arm

Download the technical data sheet

CX-T 10 render
