CX 20A
Change unit:
/
|
Engine Power |
168 - 180 kW | 225 - 241 HP |
|
Emission Level |
Stage 3/Tier 3 Stage 5/Tier 4f |
Stage 3/Tier 3 Stage 5/Tier 4f |
|
Retract force |
14.500 - 19.500 daN | 32,597 - 43,838 lbs |
|
Feed force |
5.000 - 10.000 daN | 11,240 - 22,481 lbs |
|
Feed stroke |
5.200 mm | 17' |
|
Rotary max torque |
13.000 Nm | 9,588 lb*ft |
|
Rotary max speed |
350 rpm | 350 rpm |
|
Clamping range |
85 - 205 mm | 3" 3/8 - 8" 1/16 |
|
Carousel capacity |
45 | 45 |
|
Length of rods |
3 m | 9' 10" |
|
Rod diameter |
114 mm | 4" 1/2 |
|
Weight range |
19 - 22 t | 41,888 - 48,502 lbs |
| Safety systems | ||
|---|---|---|
| Safety Protection Cage | ||
| Dust Diverter & Suppression Hood | ||
| Operator Safety Cabin | ||
| Video Cameras Kit | ||
| Rod handling systems | ||
|---|---|---|
| Automatic Rod loading system for drilling rods and DTH Hammer | ||
