CX 20

Change unit: /

Engine Power	168 - 180 kW	225 - 241 HP
Emission Level	Stage 3A/Tier 3 Stage 5/Tier 4f	Stage 3A/Tier 3 Stage 5/Tier 4f
Retract force	20.000 daN	44,962 lbs
Feed force	12.000 daN	26,977 lbs
Feed stroke	4.500 - 7.000 mm	14' 9" - 22' 11"
Rotary max torque	20.000 Nm	14,751 lb*ft
Rotary max speed	210 rpm	210 rpm
Clamping range	45 - 365 mm	1" 3/4 - 1' 2"
Weight range	17 - 19 t	37,479 - 41,888 lbs

Safety systems
Safety Protection Cage
Dust Diverter & Suppression Hood
Radiocontrol

Rod handling systems
Pipe Loader Arm

CX 20 render

Discover our RC rigs

CX 10

CX 12

CX 15

CX 20P

CX 30

CX 50

CX 20A
